NB 38 EXTRA ML

Wider tread area in comparison with NB 38 by about 23–25 %. Better stability due to wider tread area.

Find your Dealer

Wider tread area in comparison with NB 38 by about 23–25 %. Better stability due to wider tread area.

Available Tires Sizes:
10.00 - 20 | 8.25 - 20 | 9.00 - 20

Please visit the table below for more details.

Technical Data

construction-tyres-excavators-2

Download Additional Product Information

Mitas Const & Material Handling Catalogue

Technical data

Unit

Imperial

Metric

Tire size	Service description	Ply rating	Tread pattern	Type	Tube	Permitted rims	Section width - new tire(inch)	Section width - max in service(inch)	Overall diameter - new tire(inch)	Overall diameter - max in service(inch)	Static radius(inch)	Rolling circumference(inch)	Tread width(inch)	Tread depth(32nd)	Minimal dual spacing(inch)	EAN code	Pressure table	Detail

Tire size	Service description	Ply rating	Tread pattern	Type	Tube	Permitted rims	Section width - new tire(inch)	Section width - max in service(inch)	Overall diameter - new tire(inch)	Overall diameter - max in service(inch)	Static radius(inch)	Rolling circumference(inch)	Tread width(inch)	Tread depth(32nd)	Minimal dual spacing(inch)	EAN code	Pressure table	Detail
8.25 - 20	122 B		NB38 EXTRA ML	TT		6.0-206.5-207.0-20	9.2	10.0	0	39.1	18.2	116		1		8059971616965	Read More	Download PDF
9.00 - 20	140 B		NB38 EXTRA ML	TT		6.5-207.0-207.5-20	10.1	10.9	0	40.8	18.9	121		1		8059971619409	Read More	Download PDF
10.00 - 20	145 B		NB38 EXTRA ML	TT		7.0-207.5-208.0-20	10.8	11.7	0	42.4	19.6	125		1		8059971615500	Read More	Download PDF
10.00 - 20	146 B		NB38 EXTRA ML	TT		7.0-207.5-208.0-20	10.8	11.7	0	42.4	19.6	125		1		8059971619775	Read More	Download PDF
